4Post Lift CL 14,000 FP

4Post Lift CL 14,000 FP


Heavy-Duty Commercial Grade.
Wide Construction For Large Trucks.
6 Safety Locking Positions.
Single Point Air Lock Release.
Anti-Float Rub Blocks.
Lifting Capacity Safety Gauge.
Adjustable Ladders Inside Posts For Leveling Runways Without Shimming.
Diamond Plate 20" Runways.
Heavy-Duty Chain - "No Cables".
Large Heavy-Duty Hydraulic Cylinder.
High-Quality Powder Coated Blue.
Adjustable Runway Widths From 44" to 93" Wide!
Heavy-Duty 4-Post Construction.


Maximum Capacity:14,000 lbs.
Overall Height of Lift: 96"
Max. Lifting Height to Top of Runways: 71"
Max. Clearance Under Runways: 65"
Safety Locking Positions To Top of Runway:
28", 36", 44 "
52 ", 60", 68"
Max. Clearance Under Runways on Top Lock: 61"
Overall Lift Length w/ 36" Approach Ramps: 236"
Overall Lift Length w/out 36" Approach Ramps: 200"
Maximum Wheelbase: 185"
Overall Width w/ Power Unit: 137"
Outside Post Width w/Out Power Unit: 133"
Drive-Through Clearance Inside Posts: 121"
Width of Runways: 20"
Outside Width of Both Runways From 42"- 93"
Clearance Between Runways From 2" - 51"
The thickness of Runways: 6.75"
Post Dimensions: 6" x 10.5"
Lifting Speed (Approx): 90 Seconds
Power Unit: 110V or 220V
Single Phase Shipping Weight (Approx): 3,500 lbs
